E5-WP Encoder

4K60 4:4:4 Video Support

• Experience ultra-high-definition video with 4K resolution at 60 frames per second and full 4:4:4 color sampling for unparalleled image quality, suitable for professional applications where every detail matters.

Full Motion MJPEG Substream

• Maximize bandwidth efficiency and enhance video quality with a full motion MJPEG substream, delivering smooth, high-quality video feeds for preview or monitoring purposes without impacting the primary 4K60 4:4:4 video stream.

Native AES67 Audio Support

• Seamlessly integrates with AES67 audio networks, enabling high-quality, low-latency audio transmission over IP. Ensures full interoperability with other AES67-compliant devices for professional audio applications.

Dynamically Optimized (Adaptive) bit-rate compression CODEC w/ built-in AI

• Visionary’s highly efficient video compression codec is a modified full frame encoding that dynamically optimizes for fine lines (computer generated graphics) or motion video by using sophisticated AI to analyze the input source content. Actively matching the level of compression to a scene by leveraging periods of low motion video content reduces the stream’s size and enhances performance – enabling, without compromising image quality, Visually Lossless transmission of computer generated graphics or full-motion video sources.
• Adjustable Video Bitrate: (50 – 200 Mbps or Auto [800Mbps max])

Mass Configuration

• Auto Discover all endpoints on the network, export to .CSV file (all configurable parameters included), make changes offline, upload .CSV file through embedded web page of encoder/decoder and push configuration to the network
• No external software required – mass configuration capabilities built into the endpoint embedded webpage UI

LLDP Support

• Link Layer Discovery Protocol (LLDP) is a protocol used by network devices for advertising their identity, capabilities, and neighbors on a local area network based on IEEE 802 technology
• Allows for dynamic control of endpoints based on automatic discovery of physical location

QoS Support

• Quality of Service (QoS) is an advanced feature that prioritizes network traffic resulting in performance improvement for critical network traffic

HDMI 2.0 and HDCP 2.2, 2.3 Compliant

Isochronous USB 2.0 over IP

• Enables real-time data transfer for USB devices, such as webcams and microphones, over the network. This feature simplifies the deployment of video conferencing solutions and offers greater flexibility in AV system design.
  By leveraging the AV over IP infrastructure, it allows seamless integration and extension of USB peripherals.

Gigabit LAN Port for 4K60 4:4:4 Video, Control, and Powered Device (PD)

• A single Ethernet port for AV over IP, KVM over IP, USB over IP and RS-232 over IP, and POE Power Input

Enterprise Level Security –AES Encryption, 802.1x, HTTPS, SSH

Enterprise applications demand a secure Network

• AES Stream Encryption – The Advanced Encryption Standard, or AES, is a worldwide standard and was adopted as the standard encryption algorithm by the U.S. government for encrypting classified information
• HTTPS Secure API – Using secure SSL/TLS communications HTTPS provides integrity that a client is communicating with the real API and receiving back authentic data. It also ensures privacy for applications and users using the API
• 802.1x Authentication for Network access control – 802.1X provides a secure authentication mechanism for any device trying to access a network
• SSH Network Protocol – SSH is a network protocol used to remotely access and manage a device through command line communications. The key difference between Telnet (used by other AV over IP manufacturers) and SSH is that SSH uses encryption, which means that all data transmitted over a network is secure

Control

• Vision Lite Control Software
• 3rd Party Control Drivers [Crestron, QSC, Symetrix, RTI, etc.]
• *API providing access to the full range of features on the encoders and decoders offered to qualified System Integrators

Independent Routing

• Independently route all signals with the ability to separately matrix video & Bluetooth audio

Seamless Fast Switching

• Tearing free, no black screen, no frame lock

• A single Gigabit LAN Port for PoE Power, 4K60
• 4:4:4: Video, and Control
• Secure Network Isolation – VLAN Tagging separates AV traffic on the corporate network
• Easy installation in a wall, floor, or lectern
• Mounts into standard Decora style wallplates
• Easy Control Integration
• Ultra-low Latency [Sub-frame ~2ms visually lossless]
• Low bitrates
• No fiber or 10 Gigabit switch required

• Low-Cost network switches are used
• Scalable / Unlimited Distribution
• Any number and combination of inputs/outputs [in increments of one]
• Standard network cabling [CAT5e/6]
• Utilize existing network resources
• Rapid deployment
• Single network for AV and IT
• Reduced operating costs
